Project

Build an Arduino Nano TCS3200 color-sorting machine that reads candy colors and rotates a servo to route each piece into the right bin, using ShillehTek parts.

2 hr Intermediate4 parts

Project Overview

Arduino Nano + TCS3200 color sensor color sorter: In this build, a TCS3200 reads the color of a candy (M&Ms, Skittles, or any small colored object) and an MG90S servo rotates a routing arm to drop it into the matching bin.

This project combines sensing, decision-making, and actuation in one fully automated sorting machine.

Time: ~2 hours (mostly mechanical)
Skill level: Intermediate
What you will build: A motorised candy sorter that detects color and routes items to the matching bin.

Arduino Nano color-sorting machine using a TCS3200 sensor and servo to sort M&Ms into bins — TCS3200 + servo color sorter on a kitchen counter.

Parts List

From ShillehTek

GY-31 TCS3200 Color Sensor - reads the object color as RGB frequency outputs.
MG90S Metal-Gear Servo - rotates the routing arm to direct items into bins.
Arduino Nano V3.0 Pre-Soldered - runs the sensor reading and servo control logic.
120 PCS Dupont Jumper Wires - makes the sensor and servo connections easier during prototyping.

External

Bag of M&Ms / Skittles for calibration and testing
3D-printed or laser-cut sorter chassis

Note: Calibration values depend on lighting and the specific TCS3200 module. Recalibrate if you change the light source, sensor height, or enclosure.

Step-by-Step Guide

Step 1 - Build the Mechanism

Goal: Create a path that presents one candy at a time to the sensor, then reliably drops it into the correct bin.

What to do: Build the chute and bin layout so the candy passes in front of the TCS3200 and then reaches a servo-driven routing arm. Make sure the arm can swing to multiple fixed angles without binding.

Color sorter mechanism with chute, TCS3200 sensor position, and servo routing arm directing candy into bins — Drop chute to sensor, then a servo rotates a routing arm to send candy into the matching bin.

Expected result: A candy can drop through the chute, pause/align at the sensing area, and fall cleanly past the rotating arm into a selected bin position.

Step 2 - Wire It

Goal: Connect the TCS3200 sensor outputs and the servo signal to the Arduino Nano.

What to do: Wire the TCS3200 control pins S0 to S3 and the OUT pin to Arduino digital pins as shown. Connect the servo signal to D9.

Wiring diagram showing Arduino Nano connected to a TCS3200 color sensor (S0-S3 and OUT) and an MG90S servo signal on D9 — TCS3200 S0-S3 + OUT to Arduino digital pins; servo signal to D9.

Expected result: The Arduino can read pulses from the sensor OUT pin and command the servo on D9.

Step 3 - Calibrate the Sensor

Goal: Collect baseline RGB readings for your specific candy colors under your lighting conditions.

What to do: Run a calibration sketch that prints raw R/G/B values for each color. Record the values for each candy color you want to sort, then use those values to set thresholds in your main sorting logic.

Expected result: Each candy color produces a repeatable (R, G, B) triplet for your setup.

Step 4 - Upload the Main Sketch

Goal: Read the TCS3200 channels and move the servo to a bin angle based on the detected color.

What to do: Upload the sketch below to your Arduino. Update the logic and thresholds to match the calibration values you recorded.

Code:

#include <Servo.h>
const int S0=4,S1=5,S2=6,S3=7,OUT=8;
Servo arm;
int readCh(bool s2,bool s3){ digitalWrite(S2,s2);digitalWrite(S3,s3);delay(50);return pulseIn(OUT,LOW); }
void setup() {
  for (int p:{S0,S1,S2,S3}) pinMode(p,OUTPUT);
  pinMode(OUT,INPUT);
  digitalWrite(S0,HIGH); digitalWrite(S1,HIGH);
  arm.attach(9); arm.write(90);
}
void loop() {
  int r=readCh(LOW,LOW), g=readCh(HIGH,HIGH), b=readCh(LOW,HIGH);
  if (r < g && r < b)        arm.write(0);    // red bin
  else if (g < r && g < b)   arm.write(60);   // green bin
  else if (b < r && b < g)   arm.write(120);  // blue bin
  else                          arm.write(180);  // yellow / unknown
  delay(800);
  arm.write(90);
  delay(2000);
}

Expected result: The servo moves to different angles depending on the lowest channel reading and returns to center after each sort.

Step 5 - Run It

Goal: Verify that the sensor reads consistently and the servo routes candy to the correct bin.

What to do: Drop candy into the chute one at a time. Watch the servo rotate to the target position, then confirm the candy falls into the matching bin.

Arduino Nano color sorter running as the TCS3200 reads an M&M and the servo arm rotates to route it into a bin — Drop candy in, watch the arm rotate, and confirm it lands in the correct bin.

Expected result: Each candy is routed to the correct bin with minimal mis-sorts under steady lighting.

Step 6 - Where to Take It Next

Goal: Identify safe upgrades that build on the same sensor-and-actuator foundation.

What to do: If you want to expand the project, consider these directions:

Add a queue/feeder mechanism so it sorts continuously without manual drops
Use 6 bins instead of 4 and add a stepper instead of a servo for finer positioning
Log color counts to a display for an "M&M census"
Scale up to sort recycling (plastic colours), beads, or LEGO pieces

Expected result: A clear plan for your next iteration without changing the core wiring and code structure.

Conclusion

You built an Arduino Nano color-sorting machine using a TCS3200 sensor to detect color and a servo to route items into bins. With careful mechanical alignment and calibration, the sorter can automate a surprisingly reliable sense-decide-act loop.
