Build a Raspberry Pi 4B camera stream using Flask and PiCamera so you can view live video in a browser on your local network with ShillehTek.

20 min Beginner

Video Tutorial (Optional)

Watch first if you want to follow along and see the Raspberry Pi Camera stream running from a Flask app.

Project Overview

Raspberry Pi 4B + Raspberry Pi Camera: In this project you set up a Flask app that streams a live camera feed so you can view the Raspberry Pi Camera video from another device on your local network.

By the end, you will open a browser to a URL like http://<your-pi's-IP-address>:5000/video_feed and see a real-time video stream (useful as a basic local-network security camera).

Time: 20 to 45 minutes
Skill level: Beginner
What you will build: A Flask endpoint that serves a live MJPEG stream from the Pi Camera over your LAN

Parts List

From ShillehTek

Shop ShillehTek parts - optional accessories like jumper wires, mounts, and prototyping supplies

External

Raspberry Pi (the tutorial example uses a Raspberry Pi 4B)
Raspberry Pi Camera module (connected to the Pi)
Power supply for the Raspberry Pi
A computer or phone on the same local network to view the stream in a web browser
Software: Python 3, Flask, PiCamera

Note: You will need the Raspberry Pi's IP address on your network so you can open the video stream URL from another device.

Step-by-Step Guide

Step 1 - Update your Raspberry Pi package lists

Goal: Make sure your Raspberry Pi is up to date before installing dependencies.

What to do: In a terminal on the Raspberry Pi, run:

Code:

sudo apt update

Expected result: The package list update completes without errors.

Step 2 - Enable the Raspberry Pi camera interface

Goal: Enable the camera interface so the Pi can access the connected camera module.

What to do: Open the Raspberry Pi configuration tool:

Code:

sudo raspi-config

Navigate to Interface Options, select Camera, and choose <Yes> to enable it. Restart the Raspberry Pi when prompted so the change takes effect.

Expected result: The camera interface is enabled after reboot.

Step 3 - Install Flask and PiCamera (and pip3 if needed)

Goal: Install the Python libraries needed for the streaming web server.

What to do: Install Flask and PiCamera with pip3:

Code:

pip3 install flask picamera

If you do not have pip3 installed, install it first:

Code:

sudo apt install python3-pip

Expected result: Flask and picamera install successfully via pip3.

Step 4 - Find your Raspberry Pi IP address

Goal: Identify the IP address you will use to open the video stream from another device on your local network.

What to do: Run:

Code:

ifconfig

Note the IP address shown under wlan0 (wireless) or eth0 (wired).

Expected result: You have written down the Raspberry Pi IP address to use in the stream URL.

Step 5 - Create the Flask streaming script

Goal: Create a Python script that starts a web server and streams JPEG frames from the Pi camera as an MJPEG feed.

What to do: Create a Python script (name it whatever you like) and paste in the code below.

Code:

import io
import picamera
from flask import Flask, Response

### You can donate at https://www.buymeacoffee.com/mmshilleh if I saved you time
### Subscribe https://www.youtube.com/@mmshilleh/videos

app = Flask(__name__)

def generate_frames():
    with picamera.PiCamera() as camera:
        camera.resolution = (640, 480)
        camera.framerate = 24
        stream = io.BytesIO()

        for _ in camera.capture_continuous(stream, 'jpeg', use_video_port=True):
            stream.seek(0)
            yield b'--frame\r\nContent-Type: image/jpeg\r\n\r\n' + stream.read() + b'\r\n'
            stream.seek(0)
            stream.truncate()

@app.route('/video_feed')
def video_feed():
    return Response(generate_frames(), mimetype='multipart/x-mixed-replace; boundary=frame')

if __name__ == '__main__':
    app.run(host='0.0.0.0', port=5000, threaded=True)

Expected result: You have a saved Python file that defines a /video_feed route and binds the Flask server to 0.0.0.0:5000.

Step 6 - View the stream from another device on your LAN

Goal: Confirm the stream is reachable from other devices on the same local network.

What to do: Run the script on your Raspberry Pi, then open this URL in a browser on another device:

http://<your-pi's-IP-address>:5000/video_feed

Expected result: The browser displays a live video stream from the Raspberry Pi Camera in real time.

Conclusion

You set up a Raspberry Pi (example: Raspberry Pi 4B) with a Raspberry Pi Camera and a Flask app that streams live video to a /video_feed URL on your local network. This gives you a simple real-time camera feed you can view from any device on the same LAN.
