Project Overview

Arduino Nano + HC-SR04 + KY-006: Build an ultrasonic theremin where hand distance above the HC-SR04 controls pitch, and a KY-006 passive piezo buzzer plays the tone.

Wave your hand closer for a higher pitch and farther away for a lower pitch. This is a simple gesture-controlled instrument you can build quickly with inexpensive parts.

Time: ~20 minutes
Skill level: Beginner
What you will build: An ultrasonic-distance theremin that plays musical tones in response to hand height.

Arduino Nano ultrasonic theremin using an HC-SR04 distance sensor and KY-006 passive buzzer — HC-SR04 + KY-006 + Arduino Nano = a simple synthesizer you can build fast.

Parts List

From ShillehTek

HC-SR04 Ultrasonic Sensor - measures hand distance for pitch control.
KY-006 Passive Buzzer - outputs the tone generated by the Arduino.
Arduino Nano V3.0 - reads the sensor and generates the audio frequency.
Dupont Jumper Wires - quick connections between modules and the Nano.

External

Optional: a real 8Ω speaker + small amp for louder sound

Note: This build uses Arduino digital pins D9/D10 for the HC-SR04 and D8 for the buzzer, as shown in the wiring images below.

Step-by-Step Guide

Step 1 - Wire it

Goal: Connect the HC-SR04 sensor and KY-006 buzzer to the Arduino Nano.

What to do: Wire the HC-SR04 TRIG to D9 and ECHO to D10. Wire the KY-006 signal pin to D8. Provide power and ground to both modules from the Arduino.

Arduino Nano on breadboard wired to HC-SR04 on D9 and D10 and KY-006 buzzer on D8 — HC-SR04 on D9/D10; KY-006 on D8.

Arduino Nano connected to 4-wire HC-SR04 ultrasonic sensor and 2-wire KY-006 buzzer with jumper wires — 4-wire HC-SR04 + 2-wire buzzer + Arduino Nano.

Expected result: Your Nano, sensor, and buzzer are fully connected and ready for code.

Step 2 - Upload the sketch

Goal: Read distance from the HC-SR04 and convert it into an audio frequency on the buzzer.

What to do: Upload the following sketch to your Arduino Nano. It measures the pulse time from ECHO, converts it to centimeters, maps roughly 5 to 50 cm into a 200 to 2000 Hz tone range, and plays it on the buzzer.

Code:

const int TRIG = 9, ECHO = 10;
const int BUZZ = 8;
void setup() {
  pinMode(TRIG, OUTPUT);
  pinMode(ECHO, INPUT);
}
void loop() {
  digitalWrite(TRIG, LOW); delayMicroseconds(2);
  digitalWrite(TRIG, HIGH); delayMicroseconds(10);
  digitalWrite(TRIG, LOW);
  long us = pulseIn(ECHO, HIGH, 30000);
  if (us > 0 && us < 20000) {
    long cm = us * 0.0343 / 2.0;
    // Map 5-50cm to a 200-2000Hz tone range
    int freq = map(cm, 5, 50, 2000, 200);
    tone(BUZZ, freq);
  } else {
    noTone(BUZZ);
  }
  delay(50);
}

Expected result: After upload, moving your hand above the sensor should change the tone pitch.

Step 3 - Play it

Goal: Use your hand distance to control pitch like a theremin.

What to do: Hover your hand about 5 to 50 cm above the sensor and move it up and down. Closer should produce a higher pitch; farther should produce a lower pitch.

Arduino Nano ultrasonic theremin running with a hand hovering above the HC-SR04 to change buzzer pitch — Hover your hand 5 to 50 cm above the sensor; pitch slides up and down.

Expected result: You hear a continuous tone that smoothly changes pitch as your hand moves.

Step 4 - Where to take it next

Goal: Explore optional enhancements after the core build works.

What to do: If you want to extend the project, consider these ideas:

Add a second HC-SR04 for volume control (two-handed theremin)
Quantize to a musical scale (C major) so it always sounds in key
Run it through a TPA3118 amplifier for a real speaker
Add MIDI output (Pro Micro) so the theremin controls software synths

Expected result: You have clear next steps to expand the same core sensor-to-tone concept.

Conclusion

You built an Arduino Nano ultrasonic theremin using an HC-SR04 distance sensor to control pitch and a KY-006 passive buzzer to play the tone. With a few wires and a short sketch, you get a gesture-controlled instrument that responds instantly to hand height.
