Project Overview

Arduino + MAX7219 8×8 dot matrix scrolling marquee: In this build, an Arduino drives a MAX7219 LED dot matrix module (single 8×8 or chained 32×8) to display static text and smooth scrolling messages using only three control pins.

The MAX7219 can control 64 LEDs per module over an SPI-style interface. Chain multiple modules to make bright, readable desk clocks, IP-address readouts, retro scoreboards, or simple “OPEN/CLOSED” signs.

Time: ~20 minutes
Skill level: Beginner
What you will build: An Arduino driving an 8×8 (or 32×8 chained) MAX7219 display with static and scrolling text.

Arduino connected to a MAX7219 8x8 dot matrix module used for a scrolling LED marquee — The MAX7219 module controls 64 LEDs over a 3-wire control interface.

Parts List

From ShillehTek

MAX7219 8×8 Dot Matrix Module - single 8×8 display for testing static and scrolling text.
MAX7219 4-in-1 Dot Matrix (32×8) - four MAX7219 modules pre-chained for a longer scrolling marquee.
Arduino Nano V3.0 Pre-Soldered - compact Arduino board that easily drives the MAX7219 via SPI-style pins.
120 PCS Dupont Jumper Wires - quick wiring between the Arduino and the display module.

External

USB cable - for power and uploading sketches
Arduino IDE - to compile and upload the code

Note: The MAX7219 module runs from 5 V. Each fully-lit module can pull about 150 mA at max brightness. USB power is usually fine for 1 to 2 modules; for 4 modules at max brightness, use a separate 5 V supply.

Step-by-Step Guide

Step 1 - Inspect the MAX7219 module and pin labels

Goal: Identify the MAX7219 board orientation and the five input pins you will wire to the Arduino.

What to do: Look for the 8×8 LED matrix on top and the MAX7219 driver IC on the PCB. Find the input header labeled VCC, GND, DIN, CS, and CLK. The opposite header is typically the output used to chain another module.

MAX7219 8x8 dot matrix module showing the LED array and driver IC on the PCB — The 8×8 LED matrix sits on top of the MAX7219 driver IC.

MAX7219 module pinout diagram showing VCC, GND, DIN, CS, and CLK on the input header — Input side pins: VCC, GND, DIN, CS, CLK. The output header is used to chain another module.

Expected result: You know which header is the input and which pins are required to connect to the Arduino.

Step 2 - Wire the MAX7219 to the Arduino

Goal: Connect power and the three control lines so the Arduino can send data to the MAX7219.

What to do: Wire the module to your Arduino using the connections below.

Arduino wired to a MAX7219 dot matrix module using VCC, GND, DIN, CS, and CLK in an SPI-style hookup — SPI-style hookup: VCC and GND, plus DIN, CS, and CLK.

VCC → 5 V, GND → GND
DIN → D11 (MOSI)
CS → D10 (any digital pin works)
CLK → D13 (SCK)

To chain multiple modules, connect the OUTPUT header of module 1 to the INPUT header of module 2. All modules share the same CS, CLK, VCC, and GND.

Expected result: The module is powered and ready for Arduino sketches that use MD_MAX72XX and MD_Parola.

Step 3 - Install the Arduino libraries

Goal: Install the libraries needed to control the MAX7219 and display text animations.

What to do: In the Arduino IDE Library Manager, install MD_Parola and MD_MAX72XX by majicDesigns. MD_Parola provides high-level text and scrolling features, and it depends on MD_MAX72XX for the low-level driver.

Expected result: Both libraries are installed and available under your Arduino IDE examples and includes.

Step 4 - Upload a static text sketch

Goal: Verify wiring and confirm the module displays text on a single 8×8 matrix.

What to do: Upload the sketch below. If you are using a single 8×8 module, keep MAX_DEVICES set to 1.

Single MAX7219 8x8 dot matrix connected to an Arduino displaying static HI text — Static “HI” displayed on one 8×8 module.

Code:

#include <MD_Parola.h>
#include <MD_MAX72xx.h>
#include <SPI.h>

#define HARDWARE_TYPE MD_MAX72XX::FC16_HW
#define MAX_DEVICES 1     // change to 4 if using the 4-in-1 module
#define CS_PIN 10

MD_Parola display = MD_Parola(HARDWARE_TYPE, CS_PIN, MAX_DEVICES);

void setup() {
  display.begin();
  display.setIntensity(2);   // 0-15 brightness
  display.displayClear();
  display.print("HI");
}

void loop() {}

Expected result: The LED matrix displays “HI” on the module.

Step 5 - Upload a scrolling text sketch (for 32×8 / 4 modules)

Goal: Display smooth scrolling text across a chained 32×8 surface.

What to do: If you are using the 4-in-1 (32×8) module, set MAX_DEVICES to 4 and upload the sketch below.

Chained MAX7219 32x8 dot matrix connected to an Arduino showing scrolling text — Text scrolls smoothly across the matrix.

Code:

#include <MD_Parola.h>
#include <MD_MAX72xx.h>
#include <SPI.h>

#define HARDWARE_TYPE MD_MAX72XX::FC16_HW
#define MAX_DEVICES 4     // 4-in-1 module = 32×8 surface
#define CS_PIN 10

MD_Parola display = MD_Parola(HARDWARE_TYPE, CS_PIN, MAX_DEVICES);

void setup() {
  display.begin();
  display.setIntensity(3);
  display.displayClear();
  display.displayScroll("ShillehTek - IoT for Builders",
                        PA_LEFT, PA_SCROLL_LEFT, 75);
}

void loop() {
  if (display.displayAnimate()) display.displayReset();
}

Arduino IDE showing MD_Parola sketch used to scroll text on a MAX7219 dot matrix — MD_Parola handles text rendering and scrolling animations.

Expected result: Your message scrolls across the full 32×8 display.

Step 6 - Verify the marquee is running

Goal: Confirm the display is stable, readable, and scrolling smoothly.

What to do: Power the Arduino over USB, watch the text scroll, and adjust brightness with setIntensity() (0 to 15) if needed.

Finished Arduino MAX7219 32x8 scrolling LED marquee running on a desk — 32×8 chained matrix scrolling and readable across the room.

Expected result: A bright, steady scrolling marquee with no flicker or missing modules.

Step 7 - Explore next ideas

Goal: Use the same hardware and library approach to build other display projects.

What to do: Pick a direction and expand the code.

Combine with the DS3231 RTC for a scrolling-time clock display
Show live BME280 temperature/humidity readings on the marquee
Pair with an ESP32 to display incoming Telegram messages over Wi-Fi
Build a scoreboard for a custom 2-player Arduino game
Make an “open/closed” sign for a makerspace with relay-controlled shop hours

Expected result: You have a clear path to extend the marquee into a real-world project.

Conclusion

You built an Arduino-driven MAX7219 dot matrix display that can show static text and scroll messages across a single 8×8 module or a chained 32×8 marquee. With the MD_MAX72XX and MD_Parola libraries, you can quickly turn the display into clocks, signs, scoreboards, and status dashboards.

Want the exact parts used in this build? Grab them from ShillehTek.com. If you want help customizing this project or building firmware for a product or installation, check out our IoT consulting services.

Credits: The MAX7219 photos and code in this tutorial are credited to Instructables, which served as a reference for this ShillehTek version.
