Project Overview
In this tutorial, you will connect a Seeed Studio XIAO RP2040 to a BME280 environmental sensor and read temperature, humidity, and barometric pressure over I2C using MicroPython.
The XIAO RP2040 is a versatile RP2040-based microcontroller board with a dual-core Arm Cortex-M0+ and plenty of peripherals, making it a great fit for sensor monitoring and data logging.
- Time: 20 to 40 minutes
- Skill level: Beginner
- What you will build: A working BME280-to-XIAO RP2040 I2C setup that prints sensor readings continuously
Parts List
From ShillehTek
- Breadboard (optional) - makes the wiring quick and reusable
- Jumper wires - connect the XIAO RP2040 to the BME280
- Raspberry Pi Pico 2W - the microcontroller board used in this build
External
Note: This guide uses I2C on the XIAO RP2040 with SDA on Pin 6 and SCL on Pin 7, matching the MicroPython code below.
Step-by-Step Guide
Step 1 - Gather components
Goal: Make sure you have the board, sensor, and wiring ready.
What to do: Collect the Seeed Studio XIAO RP2040, a BME280 module, and 4 jumper wires (plus a breadboard if you want a cleaner setup).
Expected result: All parts are on-hand and ready to wire.
Step 2 - Wire the BME280 to the XIAO RP2040 (I2C)
Goal: Create the physical I2C connection so the RP2040 can read sensor data.
What to do: Use 4 jumper wires to connect the device as shown.
Expected result: The BME280 is powered and connected for I2C communication.
Step 3 - Install MicroPython on the XIAO RP2040 using Thonny
Goal: Flash MicroPython to the RP2040 so you can run the sensor code.
What to do: Download and install Thonny:
Open Thonny. Plug in the RP2040, but before you plug it into your computer, hold the BOOT button on the device as you plug in the USB-C.
In Thonny, go to Tools and select Interpreter. Click Install (bottom right), select the target volume and the variant you would like. The Pico H variant is fine for this tutorial. Click Install.
You can now select the device from the bottom right of the screen in Thonny to start creating files.
Expected result: MicroPython is installed and Thonny can connect to the board.
Step 4 - Install the BME280 MicroPython library
Goal: Add the driver needed to talk to the BME280 from MicroPython.
What to do: In Thonny, go to Tools > Manage Packages, then download the micropython-bme280 library.
Expected result: The bme280 module is available for import in your MicroPython code.
Step 5 - Run the MicroPython code to print sensor readings
Goal: Read BME280 values over I2C and print them continuously.
What to do: Save the following code to a file on your device and run it in Thonny.
Code:
from machine import Pin, I2C #importing relevant modules & classes
from time import sleep
import bme280 #importing BME280 library
i2c=I2C(1,sda=Pin(6), scl=Pin(7), freq=400000) #initializing the I2C method
while True:
bme = bme280.BME280(i2c=i2c) #BME280 object created
print(bme.values)
sleep(1) #delay of 10sExpected result: The serial output prints the BME280 sensor values repeatedly.
Conclusion
You connected a Seeed Studio XIAO RP2040 to a BME280 sensor over I2C and used MicroPython to continuously read and print temperature, humidity, and pressure values.
