Video Tutorial

Watch first if you want to see the full Raspberry Pi Pico W email setup using Gmail and an app password.

Project Overview

In this tutorial, you will use a Raspberry Pi Pico W with Gmail (SMTP via app password) to send an email from MicroPython. This is useful for remote monitoring, alerts, communication between devices, and periodic reporting.

• Time: 15 to 30 minutes
• Skill level: Beginner
• What you will build: A MicroPython script that connects the Pico W to Wi-Fi and sends an email through Gmail SMTP

Parts List

From ShillehTek

• Raspberry Pi Pico 2W - the WiFi microcontroller board used in this build

External

• Gmail account with Two Factor Authentication enabled
• Gmail App Password (generated after enabling 2FA)
• umail.py library (copy into the Pico filesystem)
• MicroPython environment for the Pico W (plus a way to copy files to the board)
• Wi-Fi network credentials (SSID and password)

Note: This tutorial uses a Gmail app password (not your normal Gmail password) for SMTP authentication in MicroPython.

Step-by-Step Guide

Step 1 - Enable Two Factor Authentication in Gmail

Goal: Enable 2FA on the Gmail account you will use for SMTP.

What to do: Open your Google account security settings and enable two-factor authentication for the Gmail account you will use.

https://myaccount.google.com/security

After setup, your security page should show that 2-step verification is turned on.

Expected result: Two Factor Authentication is enabled on the Gmail account.

Step 2 - Generate a Gmail App Password

Goal: Create an app password to use in MicroPython for SMTP login.

What to do: In the same Google account security area, open App Passwords and generate a new app password. The selected device type does not need to match your exact setup.

https://myaccount.google.com/security

The app password will replace your normal Gmail password for authentication in MicroPython.

Expected result: You have a generated app password ready to paste into your script.

Step 3 - Add umail.py to your Pico W filesystem

Goal: Install the MicroPython email library used by the script.

What to do: Get umail.py and copy its contents into a file named umail.py. Save it in the top-most directory on the Pico W filesystem.

Expected result: umail.py exists on the Pico W so it can be imported by your script.

Step 4 - Use the email script template (MicroPython)

Goal: Connect the Pico W to Wi-Fi and send an email using Gmail SMTP over SSL.

What to do: Copy the following script and replace the placeholder values (email, name, app password, recipient, and Wi-Fi credentials). The script connects to Wi-Fi first, then sends an email using an SMTP object.

Code:

import network
import time
import urequests

import umail

# Internal libs
import constants


# Email details
sender_email = <Your email>
sender_name = <Your name>
sender_app_password = <APP_PASSWORD>
recipient_email = <EMAIL>
email_subject ='Like, Comment, Subscribe'

def connect_to_internet(ssid, password):
    # Pass in string arguments for ssid and password

    # Just making our internet connection
    wlan = network.WLAN(network.STA_IF)
    wlan.active(True)
    wlan.connect(ssid, password)

    # Wait for connect or fail
    max_wait = 10
    while max_wait > 0:
      if wlan.status() < 0 or wlan.status() >= 3:
        break
      max_wait -= 1
      print('waiting for connection...')
      time.sleep(1)
    # Handle connection error
    if wlan.status() != 3:
       print(wlan.status())
       raise RuntimeError('network connection failed')
    else:
      print('connected')
      print(wlan.status())
      status = wlan.ifconfig()

connect_to_internet(<INTERNET_NAME>, <INTERNET_PASSWORD>)

# Send the email
# Connect to the Gmail's SSL port
smtp = umail.SMTP('smtp.gmail.com', 465, ssl=True)
# Login to the email account using the app password
smtp.login(sender_email, sender_app_password)
# Specify the recipient email address
smtp.to(recipient_email)
# Write the email header
smtp.write("From:" + sender_name + "<"+ sender_email+">\n")
smtp.write("Subject:" + email_subject + "\n")
# Write the body of the email
smtp.write("Test Email from Raspberry Pi Pico W")
# Send the email
smtp.send()
# Quit the email session
smtp.quit()

print('Email Sent')

Expected result: After you plug in your variables and run the script, the Pico W connects to Wi-Fi and the console prints Email Sent.

Conclusion

You set up a Raspberry Pi Pico W to send an email through Gmail by enabling 2FA, generating an app password, adding umail.py, and running a MicroPython SMTP script. This approach is useful for simple notifications, alerts, and lightweight reporting from your Pico W.
