Raspberry Pi + Zigbee Dongle Plus-E: Zigbee2MQTT Setup | ShillehTek

Video Tutorial (Optional)

Watch first if you want the full walkthrough for setting up Zigbee2MQTT on a Raspberry Pi with the Sonoff Zigbee 3.0 USB Dongle Plus-E.

Project Overview

Set Up Zigbee2MQTT on a Raspberry Pi: Follow this guide to configure a Raspberry Pi with the Sonoff Zigbee 3.0 USB Dongle Plus-E and a Zigbee motion sensor to run Zigbee2MQTT, providing an open MQTT bridge for Zigbee devices.

• Time: 20 to 45 minutes
• Skill level: Beginner to Intermediate
• What you will build: A Raspberry Pi running Zigbee2MQTT with a Sonoff Zigbee USB dongle and a paired Third Reality motion sensor reporting to MQTT

Parts List

From ShillehTek

• ShillehTek resources - reference guides and consulting for Raspberry Pi IoT projects

External

• Raspberry Pi 4 or Raspberry Pi 3 with Raspberry Pi OS installed
• Sonoff Zigbee 3.0 USB Dongle Plus-E (EFR32MG21 based) - the Zigbee coordinator USB dongle
• THIRDREALITY Zigbee Motion Sensor (Model: 3RMS16BZ) - example Zigbee device used for pairing
• Network access for the Pi (Ethernet or WiFi) and an internet connection for package installs

Note: Use the /dev/serial/by-id path shown by the Pi to set the serial port in configuration.yaml. The Sonoff dongle uses the ezsp adapter in this guide.

Step-by-Step Guide

Step 1 - Plug in the USB Dongle

Goal: Verify the Pi detects the Sonoff Zigbee 3.0 USB Dongle Plus-E.

What to do: Insert the Sonoff dongle into any USB port on the Raspberry Pi, then list serial devices to find the by-id path.

Code:

ls /dev/serial/by-id

Expected result: You should see an entry like usb-Itead_Sonoff_Zigbee_3.0_USB_Dongle_Plus_V2_XXXXXXXXXXXX-if00-port0 in the output.

Step 2 - Install Mosquitto (MQTT Broker)

Goal: Install and enable a local MQTT broker for Zigbee2MQTT to publish data.

What to do: Run the following commands in a terminal on the Pi.

Code:

sudo apt update
sudo apt install -y mosquitto mosquitto-clients
sudo systemctl enable mosquitto

Test:

mosquitto_sub -t zigbee2mqtt/bridge/state -v

Expected result: Nothing prints until Zigbee2MQTT starts publishing, which is normal.

Step 3 - Clone and Install Zigbee2MQTT

Goal: Get Zigbee2MQTT source and its build tools on the Pi.

What to do: Clone the repository and install Node.js and pnpm, then install dependencies.

Code:

sudo apt install -y git curl
sudo git clone https://github.com/Koenkk/zigbee2mqtt.git /opt/zigbee2mqtt
cd /opt/zigbee2mqtt

Install Node.js 18.x:

curl -fsSL https://deb.nodesource.com/setup_18.x | sudo -E bash -
sudo apt install -y nodejs

Install pnpm:

sudo npm install -g pnpm

Install dependencies:

sudo pnpm install

Expected result: Zigbee2MQTT repository is cloned and dependencies are installed to allow starting the service.

Step 4 - Configure Zigbee2MQTT

Goal: Point Zigbee2MQTT at your Sonoff dongle and enable the frontend UI.

What to do: Open the configuration file and update the serial port path to the value you found earlier.

Code:

sudo nano /opt/zigbee2mqtt/data/configuration.yaml

Example configuration:

mqtt:
  base_topic: zigbee2mqtt
  server: mqtt://localhost:1883

serial:
  port: /dev/serial/by-id/usb-Itead_Sonoff_Zigbee_3.0_USB_Dongle_Plus_V2_XXXXXXXXXXXX-if00-port0
  adapter: ezsp

frontend:
  port: 8080
  host: 0.0.0.0
  enabled: true

advanced:
  log_level: info

Reference: Example full configuration file: https://github.com/shillehbean/youtube-p2/blob/main/configuration.yaml

Expected result: configuration.yaml is updated with the correct serial port and the frontend is enabled on port 8080.

Step 5 - Start Zigbee2MQTT

Goal: Launch Zigbee2MQTT and watch it initialize.

What to do: Start Zigbee2MQTT from the project directory.

cd /opt/zigbee2mqtt
sudo npm start

Expected result: You should see output similar to:

Starting Zigbee2MQTT...
Zigbee2MQTT started!

Step 6 - Access the Zigbee2MQTT UI

Goal: Open the Zigbee2MQTT frontend to manage devices and permit joining.

What to do: In a browser on your local network go to the Pi IP and port 8080.

http://<your_pi_ip>:8080

Expected result: The Zigbee2MQTT dashboard loads. Use the Permit Join option to allow pairing.

Step 7 - Pair Your Zigbee Sensor

Goal: Pair a Zigbee device such as the THIRDREALITY motion sensor so it publishes to MQTT.

What to do: In the UI click Permit Join, then put your sensor into pairing mode by holding its pairing button until its LED blinks.

Expected result: The Zigbee2MQTT logs will show a successful interview similar to:

[info] z2m: Successfully interviewed '0xb40e060fffe0595b'
[info] z2m: Device '0xb40e060fffe0595b' is supported, identified as: Third Reality Wireless motion sensor (3RMS16BZ)

Rename the device in the UI to a friendly name like motion_office for easier automation.

Conclusion

You now have Zigbee2MQTT running on a Raspberry Pi with the Sonoff Zigbee 3.0 USB Dongle Plus-E and a paired THIRDREALITY motion sensor, publishing device data to your local MQTT broker for automation and Home Assistant integration.
