Raspberry Pi ROS 2 Humble: Install on Ubuntu 22.04 | ShillehTek

Video Tutorial (Optional)

Watch first if you want to follow the full ROS 2 Humble install on Raspberry Pi in real time.

Project Overview

In this guide, you install ROS 2 Humble on a Raspberry Pi running Ubuntu 22.04.5 LTS (Jammy) 64-bit so you can run ROS 2 nodes using a clean binary install (no compiling from source and no Docker required).

As of ROS 2 Humble, Ubuntu 22.04 receives Tier 1 support, which makes installation straightforward on arm64.

• Time: 15 to 30 minutes (depends on download speed)
• Skill level: Beginner
• What you will build: A working ROS 2 Humble environment on Raspberry Pi with a verified talker/listener test

Parts List

From ShillehTek

• ShillehTek - robotics and IoT tutorials, parts, and support

External

• Raspberry Pi (4GB or 8GB RAM recommended)
• Ubuntu 22.04.5 LTS (Jammy) 64-bit installed
• Internet access
• Raspberry Pi Imager - to flash Ubuntu to the microSD
• curl (installed via apt if needed)

Note: This install assumes arm64 on Ubuntu Jammy. In the Imager, you may see Ubuntu 22.04.3 LTS (64-bit), which upgrades to 22.04.5 via updates.

Step-by-Step Guide

Step 1 - Confirm Ubuntu is installed and update package lists

Goal: Make sure your Raspberry Pi is on Ubuntu 22.04.x and your apt package lists are current.

What to do: If you still need to flash Ubuntu, use Raspberry Pi Imager to install Ubuntu 22.04 LTS (64-bit), then boot your Pi and connect it to the internet.

Update your package list:

sudo apt update

Expected result: apt refreshes package metadata without upgrading the OS.

Step 2 - Install curl (if it is not installed)

Goal: Ensure you can download the ROS 2 repository key in the next step.

What to do:

sudo apt install curl

Expected result: curl is available on the command line.

Step 3 - Add the ROS 2 GPG key

Goal: Trust ROS 2 packages from the official ROS repository.

What to do:

sudo curl -sSL https://raw.githubusercontent.com/ros/rosdistro/master/ros.key -o /usr/share/keyrings/ros-archive-keyring.gpg

Expected result: The keyring file is created at /usr/share/keyrings/ros-archive-keyring.gpg.

Step 4 - Add the ROS 2 apt repository

Goal: Add the ROS 2 package source for Ubuntu Jammy on arm64.

What to do:

echo "deb [arch=arm64 signed-by=/usr/share/keyrings/ros-archive-keyring.gpg] http://packages.ros.org/ros2/ubuntu jammy main" | \
sudo tee /etc/apt/sources.list.d/ros2.list > /dev/null

Expected result: A new source list file is created at /etc/apt/sources.list.d/ros2.list.

Step 5 - Update apt again (now including ROS 2 packages)

Goal: Pull package metadata from the newly added ROS 2 repository.

What to do:

sudo apt update

Expected result: apt completes successfully and includes ROS 2 package listings.

Step 6 - Install ROS 2 Humble

Goal: Install ROS 2 Humble packages on your Raspberry Pi.

What to do: Install the full desktop version (includes Rviz, demos, and tools):

sudo apt install ros-humble-desktop

Or, for a minimal install:

sudo apt install ros-humble-ros-base

Expected result: ROS 2 Humble is installed and available under /opt/ros/humble.

Step 7 - Source ROS 2 in every terminal

Goal: Make ROS 2 commands (like ros2) available in your shell.

What to do: For the current terminal session:

source /opt/ros/humble/setup.bash

To make this automatic every time:

echo "source /opt/ros/humble/setup.bash" >> ~/.bashrc
source ~/.bashrc

Expected result: Running ros2 commands works in new terminals without manually sourcing.

Step 8 - Test the installation with demo nodes

Goal: Verify ROS 2 is functioning by sending and receiving messages.

What to do: In one terminal, run:

ros2 run demo_nodes_cpp talker

In another terminal, run:

ros2 run demo_nodes_cpp listener

Expected result: The listener receives messages from the talker.

Step 9 - Optional: Install build and workspace tools

Goal: Set up common development tools for building ROS 2 workspaces and managing dependencies.

What to do: Install colcon extensions:

sudo apt install python3-colcon-common-extensions

For dependency management with rosdep:

sudo apt install python3-rosdep
sudo rosdep init
rosdep update

Expected result: colcon and rosdep are installed and ready for workspace use.

Conclusion

You installed ROS 2 Humble on a Raspberry Pi running Ubuntu 22.04.5 LTS, added the official ROS 2 repository, and verified the setup using the demo talker and listener nodes.
